Screws and bolts Stainless

Stainless steel screws compliant with the standard EN ISO 3506-1:2009 are identified by a letter that indicates the class of steel and a number that indicates the type of steel, followed by a two-digit number that declares the resistance class (expressed as one tenth of the minimum tensile strength).

Other stainless steels produced by Rodacciai are suitable for the production of screws according to the American ASTM standards listed in the appropriate section.

Material designation (UNI EN ISO 3506-1 2009)

GroupQualityStrength classState
AusteniticA1
A2*
A3
A4*
A5
50Softened
70Hardened
80Highly hardened
MartensiticC150Softened
70Quenched and tempered
110
C450Softened
70Quenched and tempered
C380Quenched and tempered
FerriticF145Softened
60Hardened

* The stainless steels with a low carbon content (C ≤ 0.03%) may be marked with an L (e.g.: A2L-70).

Austenitic steels (Group A)

Quality A1: steels with the addition of sulfur to give them a great propensity for processing with chip removal. This addition makes them however more susceptible to corrosion.
Quality A2: steels that are able to satisfy many needs, primarily used in the chemical and food industries. Not resistant to chlorides, and therefore not to be used in marine environments.
Quality A3: steels with similar characteristics to those of the A2 quality, but stabilized.
Quality A4: steels that are more resistant to corrosion with respect to A2 thanks to the presence of molybdenum, which allows use in aggressive environments such as boiling sulfuric acid or in environments containing chlorides up to certain levels. Widely used in the cellulose, food and naval industries.
Quality A5: steels with similar characteristics to those of the A4 quality, but stabilized with titanium.

Martensitic steels (Group C)

Quality C1: steels with no specific resistance to corrosion, commonly used in the assembly of pumps, turbines, etc.
Quality C3: steels with a slightly greater resistance to corrosion than C1 quality, primarily used in the assembly of pumps and valves.
Quality C4: steels similar to those of C1 quality, but resulpherized. The sulfur confers greater machinability by chip removal, but further decreases the resistance to corrosion.

Ferritic steels (Group F)

Quality F1: steels that can be used in environments with a high presence of chlorides, replacing the austenitic steels A1 and A3.

Chemical composition (%) (UNI EN ISO 3506-1 2009)

GroupQualityChemical analysis
CSiMoPSCrMoNiCuTi
AusteniticA1≤0,12≤1≤6,5≤0,20,15÷0,3516÷19≤0,75÷101,75÷2,25-
A2*≤0,1≤1≤2≤0,05≤0,0315÷20-8÷19≤4-
A3≤0,8≤1≤2≤0,045≤0,0317÷19-9÷12≤1≥5xC≤0,8
A4**≤0,8≤1≤2≤0,045≤0,0316÷18,52÷310÷15max 4-
A5**≤0,8≤1≤2≤0,045≤0,0316÷18,52÷310,5÷14≤1≥5xC≤0,8
MartensiticC1**0,09÷0,15≤1≤1≤0,05≤0,0311,5÷14-≤1--
C30,17÷0,25≤1≤1≤0,04≤0,0316÷18-1,5÷2,5--
C4**0,08÷0,15≤1≤1,5≤0,060,15÷0,3512÷14-≤1--
FerriticF1***0,12≤1≤1≤0,04≤0,0315÷18-≤1--

* if the chromium content is less than 7%, the minimum nickel content must be 12%

** at the manufacturer’s discretion, the carbon content can be greater when necessary to obtain the specific mechanical characteristics for the larger diameters, but cannot in any case exceed 12% for austenitic steels

*** molybdenum may be present at the manufacturer's discretion

Mechanical characteristics – austenitic group

GroupQualityStrength classThread rangeRm1 min
(MPa)
Rp0,21 min (MPa)A2 min
(mm)
AusteniticA1, A2, A3, A4, A550≤M395002100,6d
70≤M2437004500,4d
80≤M2438006000,3d

Martensitic and ferritic groups mechanical characteristics

GroupQualityStrength classRm1 min
(MPa)
Rp0,21 min
(MPa)
A2 min
(mm)
Hardness
HBHRCHV
MartensiticC1505002500,2d147÷209-155÷220
707004100,2d209÷31420÷34220÷330
110411008200,2d-36÷45350÷440
C3808006400,2d228÷32321÷35240÷340
C4505002500,2d147÷209-155÷220
707004100,2d209÷31420÷34220÷330
FerriticF15454502500,2d128÷209-135÷220
606004100,2d171÷271-180÷285

1 The tensile strength Ris calculated on the basis of the resistant section
2 To be determined on the basis of the actual length of the screws and not on the basis of the specimen prepared for the test: "d" is the nominal diameter of the thread
3 For connection elements with a thread diameter  d>24 mm, the mechanical characteristics must be agreed upon between the buyer and the manufacturer and marked with the quality and strength class in accordance with this table
4 Tempered and hardened at a minimum hardening temperature of 275°C
5 Nominal diameter d≤24mm
